Palettes Black Hot White Hot Red Hot Fusion - Reticle 5 types 4 colors on/off - Drop Test Height 1.5 m (4.9 ft) - Boresight Adjustment Digital Controlled - Boresight Increment 0.22 mil / 0.73 MOA - Scene Mode Yes - Picture In Picture Mode (PIP) Yes - Hotspot Yes - Detector type 12 um VOx Uncooled Focal Plane Arrays - Response Waveband 8 um to 14 um - FFC (Flat Field Correction) Auto Manual External Correction - Highest Temperature Spot Tracking Yes - Standby Mode Yes - Refresh rate Sensor 50Hz / OLED 50Hz - Aperture F1.0 - Resolution 640x512 - Laser Rangefinder Up to 600 m 2 m accuracy - Laser Wavelength 905 nm - Detection Range 1750m/yd - Optical magnification 2x-16x - Lens (focal length) 35 mm - Field of view (H X) 12.52 10.03 - Digital zoom 1x 2x 4x 8x - Monitor 1024x768 0.39 inch OLED - Eye relief 45 mm - Storage Built-in 16 GB EMMC - Record Video mOn-board video recording - Capture Snapshot Yes - Battery Type One 18650 (3.7V) Lithium Rechargeable Batteries - CVBS Output Yes (via USB) - Battery Operating Time Up to 4.5 hours - Battery Capacity Display Yes - External power supply 5 VDC/2 A USB Type-C - Operating Temperature Range -20C to 55C (-4F to 131F) - Weight 652 g (1.44 lb) - Overall Dimensions 200 x 66 x 109 mm (7.8 2.6 4.3 in) - Protection Level IP67
